Product features:

1. The filter adopts disc type gl120s. Maximum flow 15m 3/ h. The filter mesh is 120 mesh (130 micron), which can be backwashed, and the filter element can be reused.

2. Electronic pulse water meter, one pulse is 1L / 10L, the water volume data is automatically transmitted to the controller, and the maximum flow is 20m 3/ h

3. Dosing device: working flow: 10l-2500l / h

Working pressure: 0.3-0.6mpa

Reagent injection speed: 0.02l-50l/h

Liquid medicine ratio: 0.2-2% (i.e. 1:500-1:50)

Operating temperature: 0-40 ℃

Motor water flow: about 0.45l per piston stroke (click twice)

4. The water pipeline is made of high-quality PVC water pipe;
